Wall mount enclosure with flat cover and latches. Made of fiberglass. Overlapping solid- and window-cover models are available. Windows are clear polycarbonate. Cover fastens with padlockable Type 316 stainless steel latches. Type 304 stainless steel piano hinges. Integral mounting brackets. Enclosures protect equipment and operators from indirect electrical contact.
Compression-molded fiberglass construction
Overlapping solid- and window-cover models are available
Windows are clear polycarbonate
Cover fastens with padlockable Type 316 stainless steel latches
Type 304 stainless steel piano hinges
Integral mounting brackets
Enclosures protect equipment and operators from indirect electrical contact
Specifications
Brand Name
nVent Hoffman
Sub Brand
J-Series
Item Name
Enclosure
Type
Two Lock, Single Door
Width
300 mm
Depth
152 mm
Height
351 mm
Cover Type
Flat Hinged with Latches
NEMA Rating
NEMA/EEMAC Type 3, 3R, 4, 4X, 12, 13, IP66
Series
J
Mounting Type
Wall
Material
Fiberglass, Plastic
Finish
Untreated
Color
7035 Light Gray
Standards
cUL Listed, UL 508A, UL File Number E54315, CSA C22.2 No 94, CSA File Number 217184
Application
Controls and Drives; Corrosive Environments
UPC
783510158880
