Vents fit on standard ProLine top with vent cutout or can be field-installed on any ProLine solid top. The Pagoda Vent features an integral centrifugal blower mounted in a housing that includes a drip-proof removable hood, wire mesh finger guard, perimeter gasket and terminal block. Electromagnetic-compatible (EMC) Pagoda Vents include a conductive screen, conductive gasket, line filter and 6-ft. power cord with stripped leads.
Integral centrifugal blower mounted in a protective housing
Can be installed on any ProLine or ProLine G2 solid top
Drip-protected, raised cover is removable from the inside of the enclosure
Housing includes a drip-proof removable hood, wire mesh finger guard and perimeter gasket
Lead wire or power cord options
115V or 230V versions
Rated UL Type 1; installing this component on an enclosure brings the enclosure rating to UL Type 1
Installation hardware included
Specifications
Brand Name
nVent Hoffman
Sub Brand
ProLine
Item Name
Vent
Type
External Mounting for ProLine Industrial Enclosures
Material
Mild Steel
Color/Finish
Powder Coated Gray
Mounting
Top
For Use With
Standard ProLine Top or Can Be Field-Installed on Any ProLine Solid Top
Includes
Centrifugal Blower, Conductive Screen, Conductive Gasket, Line Filter and 6 ft Power Cord with Stripped Leads
Standards
UL Type 1
Application
For Controls and Drives and Power Distribution
UPC
783510243791
