For roof and gutter de-icing, self regulating heating cable. 240 V, 12 W/ft in ice 32 degree F, 6 W/ft in air at 32°F (230 V, 36 W/m in ice 0 degree C, 18 W/m in air at 0°C).
Simple to design
Easy to install: cut to length, meter marks, simple fast RayClic connections
Safe and efficient in operation: no overheating, even when crossed, advanced energy saving controls
Reliable during long life: 10 year extended product warranty available, maintenance free
GM-2XT for bitumen roofs
GM-2XT for bitumen roofs
Specifications
Brand Name
Raychem
Sub Brand
RAYCHEM
Item Name
Heating Cable
Type
Self-Regulating
Number of Conductors
2
Voltage Rating
208 – 277 VAC
Core
Self-Regulating Conductive Core
Conductor Size
16 AWG
Conductor Material
Nickel Plated Copper
Wattage
39 W/m
Minimum Bend Radius
16 mm
Temperature Rating
-18 °C Installation
Insulation Material
Tinned Copper Braid
Jacket Material
Fluoropolymer
Color
Black
Standards
UL Listed, CSA Certified, FM Approved
Application
For Roofs, Gutters, Downspouts
UPC
715629006004
