Freeze protection and continuous operation up to 250°F/121°C. Maximum exposure 482°F/250°C. Safe and hazardous area. 120 V, 15 W/ft at 50°F/10°C, Fluoropolymer jacket.
Simplified design in hazardous area: T2 and T3-T6 based on systems approach
Longer circuit lengths due to larger cross section conductors
Fast installation: cut-to-length, multiple overlaps allowed, meter markings, user-friendly connections kits
Safe and efficient in operation: no overheating, uniform pipe temperatures, energy saving technology
Reliable during long life: 10 year product warranty available, maintenance free
Specifications
Brand Name
Raychem
Sub Brand
RAYCHEM
Item Name
Heating Cable
Type
Self Regulating, XTV
Number of Conductors
2
Voltage Rating
110 – 120 V
Amperage Rating
50 A
Core
Self-Regulating Conductive Core
Conductor Size
14 AWG
Conductor Material
Nickel-Plated Copper
Wattage
15 W/ft
Minimum Bend Radius
1/2 in
Temperature Rating
250 °F
Insulation Material
Fluoropolymer
Jacket Material
Fluoropolymer
Color
Red
Standards
cCSAus Certified, FM Approved, IECEx Certified
Application
For Freeze Protection of Pipes and Vessels that Require Steam Cleaning and Process Temperature Maintenance
UPC
715629419873
