Reed Manufacturing
FT2000UNIV Feed Tap Drilling Machine 09165
FEATURES:
- FT2000UNIV kit contains machine, corp adapters and cutters to saddle tap 3/4″ ﾖ 2″ for flare, compression and NPT applications.
- Compact design, featuring a separate, independent feed control for advancing the heavy-duty shell cutter into the pipe, allows the user to easily complete the tap using a drill.
- To saddle tap cast/ductile iron pipe, use drill power.
- According to Uni-Bell PVC Pipe Association recommendations, PVC and other plastic pipe must be tapped manually.Add on Reed’s 04428 and 48206 as the ratchet wrench and socket to fit the Feed Tap machine.
SPECIFICATIONS:
| Catalog Number | FT2000UNIV |
|---|---|
| Item Number | 09165 |
| Description | Complete Feed Tap Kit 3/4″ – 2″ |
INCLUDES:
- 02114 RCORP Corporation Wrench
- 02207 CW12 12″ Adjustable Wrench
- 02655 PGP10 Positive Grip Pliers
- 08358 MCR3/8 Magnetic Coupon Retainer Set, 3/8″
- 08359 MCR1/4 Magnetic Coupon Retainer Set, 1/4″
- 40296 HEX Wrench
- 04561 1/4″ PILOT DRILL BIT
- 99129 CRPD25 Coupon Retaining PILOT DRILL
- 99140 TMTC6 6oz Tapping Compound
- 09113 FTAA Arbor Assembly
- 09170 FT75CC110 3/4″ AWWA-110 Compression Corp Adapter
- 09171 FT100CC110 1″ AWWA – 110 Compression Corp Adapter
- 09172 FT150 1-1/2″ AWWA Corp Adapter
- 09173 FT150110 1-1/2″ 110 Compression Corp Adapter
- 09174 FT200 2″ AWWA Corp Adapter
- 09175 FT200110 2″ 110 Compression Corp Adapter
- 48207 FTSA1/2 Socket Adapter
- 48208 SCKT1/2 7/16″ Socket, 1/2″ DRIVE
- 99109 FT150NPT 1-1/2″ NPT (IPS,FORD) Adapter
- 99112 FT200NPT 2″ NPT (IPS,FORD) Adapter
- 99117 FT75NPT 3/4″ NPT Adapter
- 99118 FT100NPT 1″ NPT Adapter
- 99132 FTSC688 11/16″ Shell Cutter
- 99134 FTSC875 7/8″ Shell Cutter
- 99137 FTSC1438 1-7/16″ Shell Cutter
- 99138 FTSC1750 1-3/4″ Shell Cutter
