SmartGen BAC1210 Battery Charger

SmartGen BAC1210 Battery Charger

Fit with up-to-date power supply device, float charger BAC1210 is specially designed to meet the charging characteristics of the lead-acid engine starter batteries and can be used for long-term float charging of 12V lead-acid batteries.

• Power Supply(100~240)V
• Case Dimensions145.5*131*55(mm)
• Operating Temp. (-30~+55)
• Weight0.8kg

CHARACTERISTICS:

1. Switch power supply structure, wide input alternating voltage range, small size, lightweight, high-efficiency rate;

2. Automatic two-stage charging process (first constant current, then constant voltage) carried out according to storage battery charging characteristics to prevent overcharging and significantly prolong battery lifetime;

3. Built-in current protective circuit, which can give effective protection when output over current, short-circuit or reverse connection occurs. Regard power lamp or charge lamp fast blinking as an alarm.

4. Suitable for 12V storage battery and the rated current is 10A;

5. LED display: Power indication(Green light)and charging indication(Red light).
